Orchid Series – Technical Specifications (HAC-18KO | 1.5 Ton)
| Category | Specification |
|---|---|
| Power Supply | 220–240V, 50Hz |
| Min./Max. Voltage | 165V / 280V |
| Cooling Capacity (W/Btu/h) | 5200W / 18000 (4000~19500) Btu/h |
| Heating Capacity (W/Btu/h) | 5475W / 18681 Btu/h |
| Cooling Power Input | 1440W |
| Heating Power Input | 960W |
| Cooling Current | 7.12A (1.9 ~ 11.8) |
| Heating Current | 6.88A (1.9 ~ 12) |
| Rated Input | 2400W |
| Rated Current | 11.13A |
| COP | 3.66 W/W |
| Air Flow Volume (Indoor) | 900/720/610/520 m³/h |
| Dehumidifying Volume | 1.80 L/h |
Indoor Unit
| Feature | Specification |
|---|---|
| Fan Type | Cross-flow |
| Cooling Speed | 1230/1130/900/800 r/min |
| Heating Speed | 1230/1130/900/800 r/min |
| Evaporator Material | Aluminum Fin–Copper Tube |
| Evaporator Pipe Diameter | Ø7 mm |
| Evaporator Coil Size (L×D×W) | 850×25.4×342.9 mm |
| Set Temperature Range | 16~31°C |
| Sound Pressure Level (dB A) | 48/45/35/34 |
| Sound Power Level (dB A) | 58/48/47/45 |
| Dimensions (W×H×D) | 1018×327×248 mm |
| Packaging Dimensions | 1158×352×413 mm |
| Net Weight | 13.5 kg |
| Gross Weight | 16 kg |
| Compressor Trademark | GMCC |
Outdoor Unit
| Feature | Specification |
|---|---|
| Fan Type | Axial-flow |
| Fan Motor | DC |
| Fan Motor Output | 60W |
| Air Flow Volume (Outdoor) | 2800 m³/h |
| Condenser Material | Aluminum Fin–Copper Tube |
| Condenser Rows–Fin Qty | 2–1.4 |
| Condenser Rows–U Qty | 26 |
| Condenser Coil Size (L×D×W) | 892×19.05×572 mm |
| Discharge Side Pressure | 4.3 MPa |
| Suction Side Pressure | 2.5 MPa |
| Max. Allowable Pressure | 4.3 MPa |
| Throttling Method | Capillary |
| Defrosting Method | Automatic |
| Isolation | -- |
| Moisture Protection | IP24 |
| Sound Pressure Level | 56 dB (A) |
| Dimensions (W×H×D) | 890×596×372 mm |
| Packaging Dimensions | 941×653×412 mm |
| Net Weight | 36 kg |
| Gross Weight | 39 kg |
| Refrigerant Type | R410A |
| Refrigerant Charge | 1.65 kg |
Connection Pipe
| Feature | Specification |
|---|---|
| Liquid / Gas Pipe Size | 3 m |
| Gas Additional Charge | 20 g/m |
